Dr. Fischer Philips Modified HTQ 7 Textile Equip. DRF 2KW Lamp HP 70/30 (Qty. 4)
Dr. Fischer Philips Modified HTQ 7 Textile Equip. DRF 2KW Lamp HP 70/30 (Qty. 4)

Dr. Fischer Philips Modified HTQ 7 Textile Equip. DRF 2KW Lamp HP 70/30 (Qty. 4)

Regular price Rs. 99,999.00

Available. Ships within 3-4 weeks.

Note: Pricing is for Qty. 4 of the item.

Ordering code

928587505154

Family

HP

Brand

Dr. FISCHER

Applications

Copying with UV sensitive materials, Drying paints / inks / lackers, Curing adhesives (Glue / resins), Oxydation of organic polluants, Surface disinfection, Plate making (Offset printing)

Nominal wattage (W)

2000

Voltage (V)

1400

Lamp Current (A)

1,6

Power density (W/cm)

30

Arc length (mm)

700

Total length (mm)

765

Bulb diameter (mm)

14,5

Base

8

Cables (+/-5 mm)

95/95

Connection

Stripped end

Qty Box (pc)

4

UVA irrad. at 0h (µW/cm2)



UVC irrad. at 0h (µW/cm2)

1600

Diazo irrad. at 0h (µW/cm2)

1550

Burning pos.

Horiz.



In 2011, Dr. Fischer took over the medium pressure UV Lamps production equipment from Philips and started the production center at France. The integration of Philips’ entire production activities in UV and of all its employees means that Dr. Fischer Group in Pont à Mousson now has comprehensive competences for special UV solutions – from research over development, quality and production to marketing and sales.
